Always a trusted generator set supplier

KG-C Series Power By Cummins

Over the past 20 years, we have partnered with Cummins to develop the KG-C series of products. This series is favored across various sectors such as industrial, mining, power generation, healthcare, and hospitality, thanks to its high reliability and low operational cost.

The KG-C series spans a wide power range from 21kva to 3750kva, offering exceptional load acceptance capabilities, advanced efficiency, superior power performance, and reliability, ensuring a long service life. Whether it’s for bidding on projects in mining sites, power stations, hospitals, or hotels, the KG-C series provides comprehensive power solutions to meet your diverse needs.

High Quality Customisation

Product Specification

Need more information? download our product specification charts for more specific information.

50HZ

60HZ

Kingenerator Standby Power Prime Power Engine Dimension (mm) Dimension (mm)
Model KVA KVA Model Open Type Soundproof Type
KG-C24D5 24 21.5 4B3.9-G11 1760*760*1380 2300*1010*1620
KG-C30D5 30 27.5 4B3.9-G1 1760*760*1380 2300*1010*1620
KG-C30D5 30 27.5 4B3.9-G2 1760*760*1380 2300*1010*1620
KG-C34D5 34 31 4B3.9-G12 1760*760*1380 2300*1010*1620
KG-C44D5 44 40 4BT3.9-G1 1760*760*1380 2440*1090*1630
KG-C44D5 44 40 4BT3.9-G2 1760*760*1380 2440*1090*1680
KG-C65D5 65 56 4BTA3.9-G2 1760*760*1380 2440*1090*1680
KG-C70D5 70 65 4BTA3.9-G2 1760*760*1380 2440*1090*1680
KG-C90D5 90 80 4BTA3.9-G11 1760*760*1380 2600*1100*1680
KG-C103D5 103 94 6BT5.9-G1 2300*830*1700 3000*1200*1800
KG-C103D5 103 94 6BT5.9-G2 2300*830*1700 3000*1200*1800
KG-C105D5 105 95 4BTA3.9-G13 1850*800*1380 2800*1060*1680
KG-C110D5 110 100 4BTAA3.9-G3 1850*800*1380 2800*1060*1680
KG-C115D5 115 105 6BT5.9-G2 2300*830*1700 3000*1200*1800
KG-C125D5 125 115 6BTA5.9-G2 2300*830*1700 3000*1200*1800
KG-C145D5 145 135 6BTAA5.9-G2 2350*830*1700 3300*1200*1800
KG-C165D5 165 150 6BTAA5.9-G12 2390*860*1750 3300*1200*1800
KG-C200D5 200 181 6CTA8.3-G1 2390*860*1750 3300*1200*1800
KG-C200D5 200 181 6CTA8.3-G2 2390*860*1750 3300*1200*1800
KG-C215D5 215 200 6CTAA8.3-G2 2450*960*1750 3400*1300*1900
KG-C250D5 250 NA 6CTAA8.3-G9 2500*960*1750 3400*1300*1900
KG-C265D5 265 250 6LTAA8.9-G2 2500*960*1750 3590*1310*2050
KG-C275D5 275 250 6LTAA8.9-G3 2500*960*1750 3590*1310*2050
KG-C300D5 300 270 6LTAA9.5-G3 2500*1160*1850 3690*1460*2150
KG-C350D5 350 320 6LTAA9.5-G1 2500*1160*1850 3690*1460*2150
KG-C425D5 425 388 6ZTAA13-G3 2900*1200*1750 4000*1800*2150
KG-C475D5 475 438 6ZTAA13-G2 2900*1200*1750 4000*1800*2150
KG-C500D5 500 475 QSZ13-G3 3400*1258*2050 4300*1800*2300
KG-C550D5 550 500 QSZ13-G10 3400*1258*2050 4630*2100*2250
KG-C275D5 275 250 MTA11-G2 3000*1150*1850 3890*1460*2150
KG-C275D5 275 250 NT855-GA 3020*1100*1850 3890*1460*2150
KG-C313D5 313 275 NTA855-G1A 3020*1100*1850 3890*1460*2150
KG-C350D5 350 313 MTAA11-G3 3020*1100*1850 3890*1460*2150
KG-C350D5 350 320 NTA855-G1B 3020*1100*1850 4300*1800*2300
KG-C375D5 375 344 NTA855-G2A 3020*1100*1850 4300*1800*2300
KG-C388D5 388 350 NTA855-G4 3020*1100*1850? 4300*1800*2300
KG-C415D5 415 375 NTAA855-G7 3090*1100*1850 4300*1800*2300
KG-C415D5 415 375 KTA19-G2 3300*1258*2050 4300*1800*2300
KG-C438D5 438 400 QSNT-G3 3090*1300*1850 4300*1800*2300
KG-C450D5 450 NA NTAA855-G7A 3090*1100*1850 4300*1800*2300
KG-C500D5 500 450 QSNT-G4X 3090*1300*1850 4300*1800*2300
KG-C500D5 500 450 KTA19-G3 3400*1258*2050 4300*1800*2300
KG-C563D5 563 500 KTA19-G3A 3400*1258*2050 4300*1800*2300
KG-C563D5 563 500 KTA19-G4 3400*1258*2050 4630*2100*2250
KG-C631D5 631 525 KTAA19-G5 3650*1638*2050 5030*2200*2550
KG-C650D5 650 575 KTAA19-G6 3650*1638*2050 5030*2200*2550
KG-C650D5 650 NA KTA19-G8 3650*1500*2050 5030*2200*2250
KG-C688D5 688 NA KTAA19-G6A 3650*1500*2050 50300*2200*2250
KG-C715D5 715 650 QSK19-G4 3650*1638*2050 5030*2200*2550
KG-C700D5 700 625 KT38-G 4200*2100*2320 5030*2200*2600
KG-C800D5 800 725 KT38-GA 4200*2100*2320 5030*2200*2600
KG-C825D5 825 750 KTA38-G2 4200*2100*2320 6000*2400*2690
KG-C888D5 888 800 KTA38-G2B 4200*2100*2320 6000*2400*2690
KG-C1000D5 1000 910 KTA38-G2A 4200*2100*2320 6000*2400*2690
KG-C1100D5 1100 1000 KTA38-G5 4750*2100*2320 6000*2400*2690
KG-C1250D5 1250 NA KTA38-G9 5000*2200*2500 7000*2400*2690
KG-C1375D5 1375 1250 KTA38-G9A 5000*2200*2500 7000*2400*2690
KG-C1375D5 1375 1250 KTA50-G3 5000*2200*2500 7800*2400*2690
KG-C1375D5 1375 1275 KTA50-G12 5780*2200*2800 ISO 20'ft HQ
KG-C1500D5 1500 1375 KTA50-G7E 5780*2200*2800 ISO 20'ft HQ
KG-C1600D5 1600 1375 KTA50-G12A 5780*2200*2800 ISO 20'ft HQ
KG-C1650D5 1650 1375 KTA50-G8 5780*2200*2800 ISO 20'ft HQ
KG-C1650D5 1650 1475 KTA50-GS8 5780*2200*2800 ISO 20'ft HQ
KG-C1875D5 1875 1675 KTA50-G15X 6000*2500*2800 ISO 40'ft HQ
KG-C2000D5 2000 1875 KTA50-G16A 6000*2500*2800 ISO 40'ft HQ
KG-C2062D5 2062 2000 KTA50-G16B 6000*2500*2800 ISO 40'ft HQ
KG-C2250D5 2250 2045 QSK60-G4 6250*2500*2800 ISO 40'ft HQ
KG-C2500D5 2500 2250 QSK60-G21 6450*2500*2800 ISO 40'ft HQ
KG-C2750D5 2750 2500 QSK60G22 5900*2300*2800 ISO 40'ft HQ
KG-C2750D5 2750 2500 QSK60G23 5900*2300*2800 ISO 40'ft HQ
KG-C3000D5 3000 2750 QSK78-G9 7300*2910*3400 ISO 40'ft HQ
KG-C3500D5 3500 3125 QSK95-G5 8000*3000*3700 ISO 40'ft HQ
KG-C3760D5 3760 3360 QSK95-G4 8000*3000*3700 ISO 40'ft HQ
